Technical 3D model of a spur gear.
Teeth count: 20.
Outer diameter: 18.31 mm.
Root diameter: 16.06 mm.
Tooth...
Technical 3D model of a spur gear.
Teeth count: 20.
Outer diameter: 18.31 mm.
Root diameter: 16.06 mm.
Tooth...
Model details
- Access Free download
Description
Overview and production context
Technical 3D model of a spur gear. Teeth count: 20. Outer diameter: 18.31 mm. Root diameter: 16.06 mm. Tooth height (depth): 1.00 mm. Tooth thickness at base (root): 1.50 mm. Tooth thickness at tip: 1.00 mm. Gear face width: 7.20 mm. Total part height: 13.01 mm. Bore: D-shaped hole, 6.00 mm diameter with a 5.20 mm flat cut. Features: Symmetrical locking tabs (5.00 mm wide) on both faces. Style: Trapezoidal tooth profile, sharp mechanical edges, CAD precision, high polygon density.
